X-130 Automatic Label Stripping Machine Labeler Dispenser 130mm/sec 250mm max. dia 110/220V50/60Hz

商品説明

1PC X-130 Automatic Label Stripping Machines Labeler Dispenser Labeler Dispenser 130mm/sec 250mm max. dia
Features:
1.Suit for kinds of label but not for transparant label
2.When remove liner scrap frequently due to a long label length
3.With delicate and cabinet appearance,low failure rate
4.Best choice for small labels and small work areas
5.The machine can dispense labels and die-cut parts
6.Automatically rewind liner scrap for cleaner working environment
7.High torque motor for wide diameter label rolls,high quality products


Using instruction:
1.Wrapped the label on the hanging boardas the picture shows and fixed with positioning plate
2.Insert the guide plate and insert the label between the label delivery board and the middle stick,show U shape,then adjust the guide board according to the label width
3.Please hang the label into the roll paper device,open the upper device and put the label into the 3 sticks of roll parper device
4.Clock the interlock lever,press the interlock lever botton till hear the clocked arlaming
5.Open the power botton which behind right direction
6.When the machine in stripping labels,pls get the labels from the bottom up

Remark: When you getting the label,it may cover the sensor by wrong way to get to label, Pls pay your attentation use the machine in right way

Specification:
Model: X-130
Voltage: 110/220V50/60Hz
Stripping speed: 130mm/sec
Label width: 5-130mm
Max Label Dia: 250mm
Label length: 15-200mm
Dimession: 166*174*280mm
