BSIDE ADM02 マルチメーター オートレンジ バックライト オートオフ ローバッテリー通知 電圧 電流 抵抗 導通 周波数 ダイオード
- メーカー
- BSIDE
- JAN
- 0678358851713
- メーカー品番
- ADM02
- この商品のレビュー
- Amazonでのレビュー
- シェア
商品説明
NOTE:
（1） After auto power off in the AC mode, if changing the rotary switch to the DC mode, the Re-power on if disabled.
(2) The meter enters sleep mode after Auto power off. If press “HOLD” push button to re-power on in the sleep mode, the auto power off function is disabled.
● Operating temperature & Humidity:
0 ~ 40℃ (32 ~104 ℉) & < 80% RH
● Storage temperature & Humidity:
-10 ~ 50℃ (14 ~ 122 ℉) & <70%RH
● Power Supply: 9V Battery(6F22 or 1604A Type) x 1pc.
● Safety Class: IEC 61010-1, CAT II 600V.
● Dimension(L x W x H) & Weight:140 x 67 x 30mm, Approx.
特記事項
- AideTek ADM02 auto range multimeter DMM ohm AC DC buzz diode Temp backlight auto power off compared w/ FLUKE
- Auto ranging DMM , that full scale is 2000 counts ,Display : 3 1/2 digit LCD display
- Over load protection: Used the PTC protection circuit for Resistance, temperature measurement.,DATA HOLD function
- MAX value hold function , Back Light, Low battery indication
- Auto Power OFF. : If the meter is idle for 15 minutes (idle time), the meter automatically turns the power off. After auto power-off, pushing any of the push button or changing the rotary switch can turn on the meter again.
