デジタル オシロスコープ DIYキット Digital Oscilloscope DIY Kit

商品説明

Features:
- 9VDC power supply voltage
- <280mA current draw
- 5M samples/second (AUTO mode only)
- 8 bit resolution
- 256 sample memory depth
- 1MHz analog bandwidth
- 100mV/Div-5V/Div sensitivity
- 1MΩ impedance
- 50Vpeak-to-peak max input voltage
- DC/AC coupling
- Save and display up to 6 captures to memory
- Transfer screen capture to PC as a bitmap file (serial adapter not included)
- Backlit LCD display
- BNC Connector
- Dimensions:
- 110x65x25mm
- Weight: 70g

資料：
『組み立て説明書』（Assembly Instructions）
http://www.jyetech.com/Products/LcdScope/Assembly%20Notes_062C.pdf

『操作説明書』（Operating Instructions）
http://www.jyetech.com/Products/LcdScope/Operating%20Instructions_062C.pdf

『パーツリスト』（Parts List）
http://www.jyetech.com/Products/LcdScope/PartList_062C.pdf

『トラブルシューティング』（Troubleshooting）
http://www.jyetech.com/Products/LcdScope/Troubleshooting_062C.pdf
