Copper busbar bending machine hydraulic bus bar bending tool CB-150D
- メーカー
- MXBAOHENG
- JAN
- 6021421026251
- メーカー品番
- LX26
- この商品のレビュー
- Amazonでのレビュー
- シェア
商品説明
CB-150D Copper busbar bending machine
Item specifics
is_customized: Yes
Brand Name: yindu
Type: Other
Model Number: CB-150D
Colour: yellow,black
Material: steel
Operation: manual
Power: from pump pressure
Pump: manual pump or electric pump
Features&functions:
This busbar bending machine is a kind of flat bend copper,aluminum busbar dedicated equipment.CB-150D and CB-150B use bolt type structure,easy access to rows of copper and aluminum,equipped with supporting frames to ensure that copper and aluminum row center line and the centerline of the piston in the same plane.CB-200A and CB-150A use a fixed structure,durable and the plane bending die used to do support.It it equipped with pumps to use.
Product Description
Punching Force 20Ton
Bending Max.Thickness 10mm
Bending width 150mm
Weight approx.21kg
Package Wooden box
Size 290X220X400mm
Note hand pump CP-700/electric pump ZCB-700A
We will arrange the shipment in 2-5 working days and it takes another 3-7 working days to reach you.
特記事項
- 1. Used for bending copper and aluminum busbar and steel bar.2. Could bend different angle
- 3.With width piston unit set,busbar will not get distort after bending.
- 4.The tool body could be opened so that bended object could be easily taken out after bending.
- 5.Portable unit could be taken to site or fixed in factory for batch bending works.
- 6.Max bending angle 90 degree. 7.Bended objects won't be damaged.
