BT101F Flow Intelligent Peristaltic Pump Single Channel Flow Range 0.0001~720ml/min 110V or 220V Pump Head Optional (YZ15 Pump Head)
- メーカー
- MXBAOHENG
- JAN
- HQ-1330
- メーカー品番
- HQ-1330
- この商品のレビュー
- Amazonでのレビュー
- シェア
商品説明
The product usually takes 7--13 business days to arrive to your hand after your order is confirmed
Parameters:
Model; BT101F
Flow range: 0.0001~720ml/min
Speed range: 150r/min
Speed measurement: 0.1
Speed accuracy error: <0.5%
Voltage: 220v/110v 50hz/60hz
Power: <30w
Support RS485 bus, MODBUS communication protocol
Working Environment Temperature: 0 ~ 40 ? Relative humidity <80%
Protection level: IP31
Dimensions: (L ?W ?H) 257mm?80mm?97mm
Weight: 4.5kg
YZ15 Pump Head
Suitable flexible pipe: 13#14#16#19#25#17#
Flow rate: 0.006~420ml/min
YZ25 Pump Head
Suitable flexible pipe: 15#24#
Flow rate: 0.16~420ml/min
YT15 Pump Head
Suitable flexible pipe: 13#14#16#19#25#17#18#
Flow rate: 0.006~570ml/min
YT25 Pump Head
Suitable flexible pipe: 15#24#35#36#
Flow rate: 0.16~720ml/min
特記事項
- Color LCD displaying, touch screen and keypad for operating. Three types of distributing mode: time dispensing mode; volume dispensing mode; copy dispensing mode.
- Automatically store five groups of working parameters (power-off memory). Precise motor control technology improves dispensing accuracy compared to the traditional time dispensing mode. Remote infrared control (optional).
- Easy button control to reverse direction, start/stop and run full speed (for cleaning). 0.1 rpm speed resolution. Display and control flow rate, accumulated dispensing volume automatically. Flow rate calibration.
- Professional operating system. Intelligent temperature-control technology reduces working noise. External on/off voltage control signal controls start/stop, reversible direction and easy dispensing function, optically coupled isolator; external analog control signal adjusts the rotating speed. With RS485 MODBUS interface, easy to be controlled by other devices.
- Internal double-deck isolation structure; circuit board with conformal coating makes it dust-proof and moisture-proof. Anti-interference feature, wide input voltage range for complex power environment. ABS plastic housing, creative streamlined appearance. Drive multi-channels and various types of pump heads. ptional footswitch or timer for dispensing fluid.
