モリス製品97872ブラック絶縁マウント可能 - デュアル入力2ポート750から250

メーカー
Morris Products
JAN
0601986978729
メーカー品番
97872
この商品のレビュー
Amazonでのレビュー
シェア

商品説明

Black Insulated Mountable - Dual Entry 2 Ports 750 - 250 - Our Dual Entry Connector makes quick work of electrical connections.

Features :
  • Dual entry connector has isolated bolt holes for mounting to trough, panel or wireway.
  • Insulated with rugged high-dielectric rubber/vinyl coating.
  • Wire entry from either side.
  • Pre-filled with oxide inhibitor.
  • Plugs marked with connector max wire size for easy identification.
  • Dual entry connector is 6061 aluminum dual rated for use with copper and/or aluminum wires.
  • One wire per terminal.
  • CCSAus Certified through 600MCM size.
  • Rated 90°C 600 Volt.
Specification :
  • Wire Ports - 2.
  • Wire Range: 750 - 250.
  • Allen Hex: 3/8 in.
  • Bolt - 3/8 in.
  • Length: 6.19 in.
  • Height: 3.6 in.
  • Item weight - 1.83 lbs.

特記事項

Morris Products 97872 Mountable Multi-Cable Connector, Insulated, Dual Entry, Black, 2 Ports, 3/8 Allen Hex, 750 - 250 Wire Range
