Nucleo NUCLEO-L053R8 STM32L053R8 STM32 Development Board Integrate ST-LINK/V2-1 Debugger Programmer Support Arduino ST Morpho Headers
- メーカー
- SUNKEE
- ブランド
- Sunkee
- JAN
- 0786561883534
- メーカー品番
- WXST3012
- この商品のレビュー
- Amazonでのレビュー
- シェア
商品説明
Features:
•STM32 microcontroller with LQFP64 package: STM32L053R8T6 ( 64K FLASH )
•Two types of extension resources: Arduino Uno Revision 3 connectivity ,
STMicroelectronics Morpho extension pin headers for full access to all STM32 I/Os
•mbed-enabled (mbed.org)
•On-board ST-LINK/V2-1 debugger/programmer with SWD connector: selection-mode
switch to use the kit as a standalone ST-LINK/V2-1
•Flexible board power supply:USB VBUS or external source(3.3 V, 5 V, 7 - 12
V) , Power management access point
•Three LEDs : USB communication (LD1), user LED (LD2), power LED (LD3)
•Two push buttons: USER and RESET
•USB re-enumeration capability: three different interfaces supported on USB
:Virtual Com port, Mass storage,Debug port
•Comprehensive free software HAL library including a variety of software examples
•Supported by wide choice of Integrated Development Environments (IDEs) including
IAR, Keil, GCC-based IDEs
Package included:
•1 X NUCLEO-L053R8
特記事項
- STM32 microcontroller with LQFP64 package: STM32L053R8T6 ( 64K FLASH ) Two types of extension resources: Arduino Uno Revision 3 connectivity , STMicroelectronics Morpho extension pin headers for full access to all STM32 I/Os
- On-board ST-LINK/V2-1 debugger/programmer with SWD connector: selection-mode switch to use the kit as a standalone ST-LINK/V2-1
- Flexible board power supply:USB VBUS or external source(3.3 V, 5 V, 7 - 12 V) , Power management access point
