Seesii 7" CCTV Security Camera Tester Monitor Analog HDMI VGA Cable Scan HVT-3600 Zoom With Key Chain [並行輸入品]
- メーカー
- Seesii
- JAN
- 0889251056246
- メーカー品番
- HVT-3600
- この商品のレビュー
- Amazonでのレビュー
- シェア
商品説明
Network cable and Telephone cable testing, display the sequence of connection and the NO of the LAN cable,support RS232/RS485 /RS422,Rate 600 ~ 115200bps adjustable. Features:
1. English/Chinese and other languages optional
2. 7inch TFT-LCD, 1024(RGB)×600 resolution,16:9 NEW
4. VGA, HDMI signal input display, convenient to DVR / NVR setting NEW
5. DC12V 2A power output for camera NEW
6. 6,USB 5V 2A power out, as a power bank NEW
7. 7,LED Lamp,easy to operate at night
8. 8,Micro SD card moveable
9. 9,User- defined shortcut keys(F1 and F2)
10 10,LCD screen brightness/contrast/color Saturation adjustable
11 11,Automatically adapts and displays the video format of NTSC/PA
12 12,Enhanced color bar generator, by receiving the video color bar to test the video channel whether transmit normally
15. 10xzoom,video image can be magnified to view the details, easy to use (only for analog video test)
16. Video record and playback (only for analog video test)
17. Snapshot and save the current image as JPG file in the SD card(only for analog video test)
18. PING testing,test IP camera or other network devices' Ethernet port whether work normally, and the IP address whether right
19. Video signal level test
20. PEAK video signal level, SYNC signal level, COLOR BURST chroma level measurement *NEW
21. Cable scan, Send the specific signal, easy to find the connected cable
22. IP address scan, quickly search the IP address for the connected IP camera and other network devices
23. POE voltage measurement,test the PoE switch's voltage to IP cameras, wireless AP device and other PD devices
24. Device Port flicker,easy to find the connected PoE switch port by sending special signals, the connected PoE port will flicker at special frequency
25. Link monitor; check the setting IP address whether occupied
27. PTZ address scan, search up the ID of PTZ camera
特記事項
- 新品、並行輸入品です。Brand new parallel imports from the US.
- The device is high power-efficient, energy saving and environmental protection. It can last 17 hours for normal use after charging for 7 -8 hours
- Audio input test, test the audio signal from pickup devic
- PTZ control. Pan/tilts the P/T unit, zooms in/out the lens, adjusts the focus, aperture and sets and the preset position,PTZ protocol analysis, control protocol command displays to check RS485 transmission whether is normal, easy to find the fault device
- Multi-protocol. Supports more than thirty PTZ protocols. Such as PELCO-P, PELCO-D, SAMSUNG
