[UMKTOKYO] 音声認識モジュール Speak Recognition Voice Recognition Module V3 with Microphone
- メーカー
- UMKTOKYO
- JAN
- 0786561627268
- メーカー品番
- AD000338
- この商品のレビュー
- Amazonでのレビュー
- シェア
商品説明
1.Digital Interface: 5V TTL level for UART interface and GPIO 2.Analog Interface: 3.5mm mono-channel microphone connector + microphone pin interface 3.Size: 31mm x 50mm 4.Recognition accuracy: 99% (under ideal environment)
特記事項
- This product is a speaker-dependent voice recognition module. It supports up to 80 voice commands in all. Max 7 voice commands could work at the same time. Any sound could be trained as command. Users need to train the module first before let it recognizing any voice command.
- This board has 2 controlling ways: Serial Port (full function), General Input Pins (part of function).
- On V3, voice commands are stored in one large group like a library. Any 7 voice commands in the library could be imported into recognizer. It means 7 commands are effective at the same time.
- Voltage: 4.5-5.5V,Current: <40mA
